power supply units

AC-dc chargers

PALSTAR SPS 8250

Current 25 Amp Continuous - 30 Amp peak

Variable Voltage 3-15 V DC

Twin Meters for Current/Voltage

High Efficiency

Lightweight 2.6Kg

Size: 220 (w) x 100 (h) x 220 UK p&p £14 mm

Protected for :-

Over voltage
Over current
Over Temperature
High RFI Stability

The SPS-8250 switch mode DC Power Supply provides high power output with its small size and lightweight. It is suitable for a variety of uses, especially for DC operated radio equipment source from an AC outlet & providing variable voltages of 3V to 15V under 25A continuous operation.

£109.95

EP-925 Manson 25A 3-15V Variable Power Supply

3-15 V DC Adjustable Output

Fixed voltage mode at 13.8V DC

Overload and Short circuit Protection

Overload Warning LED

High stability

Precision Ammeter and Voltmeter

One Screw On and 2 Snap On terminals

Galvanized Steel Case

Fan Cooling system.

Output voltage : 3-15VDC Adjustable or Fixed 13,8VDC

Rated output current : 25A

Peak current : 30A

Ripple and noise : 10V r.m.s.

Line regulation : 15mV

Load regulation : 100mV

Power source : 230VAC/50Hz (or on request)

Meter type : analogue Voltage, analogue Current

Voltage meter : 0-20V

Current meter : 0-30A

Meter's accuracy : 7% fsd

Thermostatic Control Fan

Protection Overload, Short Circuit

For indoor use only

Approvals : CE EN60065 EN55014

Dimension : 150x145x300 (mm) (W x H x D)

Weight : Approx. 9Kg

Note:
PALSTAR PS-30M identical to MANSON EP-925 may be substituted instead

Price: £109.95

PALSTAR PS15 15A Power Supply

A good quality 15A power supply with built-in cooling fan.

Banana sockets for high current output.

Two sets of spring terminals for low current accessories.

Price: £69.95

KPS-280A Power Supply Unit

Input voltage: 110 or 220V AC (+/-10%) Switchable

Output voltage: 13.8V 9 to 15V DC adjustable

Current rating: 28A

Current continuous: 25A

Over-voltage protection: 16V (+/- 0.5)

Ripple and noise: peak-to-peak, ripple and noise is less than 0.3%

Efficiency: 75%

Dimension (L x W x H): 170 x 145 x 110mm

Net weight: 1.8kg

Short circuit and over voltage protection

Output power rated at continuous service

Binding post output terminals

Precision regulation of output voltage

Low peak-peak ripple of less than 0.3%

External fuse access

High surge capacity

Heavy duty metal cabinet with power coating

£84.95

KPS-450A Power Supply Unit

Input voltage: 220V AC rms +/-20% or 110VAC rms +/-20%

Output voltage: 13.8V (9 to 15V ADJ.)

Current rating: 45A

Current continuous: 40A

Output noise and ripple: 100mVp-p maximum at DC-10MHz

Output over voltage protection: 17V (+/-1)

Output short protection

Cooling: forced air cooling by built-in DC fan

Size (L x W x H): 9 x 7.25 x 4.75 inches

£139.95

MANSON EP-925 Power Supply Unit

Output voltage 3 - 15V DC

Output Current 25A (30A peak)

Malfunction protected

Dual meters for volts & current

Front panel terminals

Supply 230V AC 50Hz

Weight 9.2kg

Note:
PALSTAR PS-30M identical to MANSON EP-925 may be substituted instead

£109.95

KPS-1225 Power Supply Unit

Output voltage: 13.8V

Current rating: 10A

Current continuous: 10A

Output noise and ripple: 100mVp-p maximum at DC-10MHz

Output over voltage protection: 17V +/- 1V

Output short protection

Cooling: forced air cooling by built-in DC fan

Size (L x W x H): 9 x 7 x 2.5 inches

£55.95

CA441-2S Drop-in-charger for Alan441 PMR.

CA441-2S

Double Slow Charger
Wall Adapter
2 Ni-MH Battery Packs
2 Battery Covers

Price: £26.95
